Jiaxing Xingjie Machinery Co., Ltd. is one of the most reliable manufacturers and suppliers of 2 inch swivel casters in China. With a professional production team, we are able to meet the needs of the majority of our customers. Welcome to buy premium 2 inch swivel casters made in China here from our factory.
Products Description
The 2 inch swivel caster is a low-profile, heavy-duty mobility solution engineered for cabinets, equipment, server racks, medical devices, and industrial enclosures requiring stable, reliable movement. With a 100kg load capacity per caster and a low 73mm load height, this low center of gravity caster provides stable support with smooth 360° swiveling and a compact 50 × 43mm wheel for excellent load distribution - essential for applications where equipment stability and low-profile design are priorities.
The impact on your daily operations: When heavy cabinets and equipment need to be repositioned for maintenance, reconfiguration, or relocation, a low center of gravity caster reduces the risk of tipping and provides stable, predictable movement. The low 73mm load height keeps the equipment close to the ground, improving stability during transport - particularly important for tall cabinets, server racks, and equipment with high centers of gravity. The PA (nylon) wheel delivers excellent wear resistance and low rolling resistance - allowing equipment to move smoothly with minimal effort. The compact 50mm diameter with 43mm wide wheel provides superior load distribution compared to standard narrow wheels.
The PA (nylon) wheel offers excellent wear resistance, impact strength, and low rolling resistance - making it ideal for industrial and commercial applications where reliability and durability are essential. Nylon maintains its structural integrity under heavy loads, resists wear from frequent use, and performs consistently across a range of floor types. The wide 43mm wheel width distributes load more effectively, reducing pressure on floors and improving stability during movement. The 2-inch swivel design ensures 360° steering capability, allowing equipment to turn smoothly in tight spaces and narrow aisles.
Available with top plate mounting (92.2 × 60.4mm, bolt hole spacing 76.2-68.4 × 44.4mm) for secure attachment to cabinets, equipment, and enclosures. The low-profile design with 15mm offset provides compact maneuverability while maintaining load stability - making this 2 inch swivel caster the ideal choice for server cabinets, equipment, and low-profile industrial applications.
Technical Specifications
|
Parameter |
Specification |
|
Model No. |
302S1ZSWS217N |
|
Caster Type |
Swivel Caster (Low Profile) |
|
Wheel Diameter |
50 mm (2″) |
|
Wheel Width |
43 mm |
|
Wheel Material |
PA (Nylon) |
|
Load Capacity |
100 kg per caster |
|
Mounting Type |
Top Plate |
|
Top Plate Size |
92.2 × 60.4 mm |
|
Bolt Hole Spacing |
76.2-68.4 × 44.4 mm |
|
Offset |
15 mm |
|
Load Height |
73 mm |
Key Features
100kg Load Capacity - heavy-duty support in a compact 2-inch caster
Low 73mm Load Height - low center of gravity for enhanced equipment stability
Wide 43mm PA (Nylon) Wheel - superior load distribution and wear resistance
Smooth 360° Swivel Action - effortless steering and maneuverability in tight spaces
Top Plate Mounting - 92.2 × 60.4mm plate for secure attachment
Low Profile Design - 15mm offset for compact maneuverability with load stability
Why Choose Xingteng TENG® Casters?
30+ Years of Manufacturing Excellence
Xingteng Group has been manufacturing casters since 1997, with manufacturing origins predating our official registration. With over 30 years of continuous innovation and quality improvement, our experience means we understand not just how to make casters, but how to make them right for your specific application - especially when it comes to low-profile swivel casters for cabinets and industrial equipment.
ISO 9001:2015 Certified Quality Management
Our quality management system is certified to ISO 9001:2015, ensuring consistent product quality, traceable production processes, and continuous improvement - exactly what equipment and cabinet buyers expect from a reliable supplier.
TUV Product Certification
Multiple product series have passed TUV testing and certification - proof that our products meet internationally recognized safety and performance standards.
RoHS 2.0 Compliant
All products meet RoHS 2.0 European environmental protection standards, ensuring your supply chain remains compliant with international environmental regulations.
In-House Testing Laboratory
Our dedicated testing facility is equipped with dynamic loading testers, impact testers, static pressure testers, hardness testers, brake life testers, salt spray testers, optical profile projector, and caster creep tester - every 2 inch swivel caster is verified before it leaves our factory.
30,000+ sqm Manufacturing Facility
Annual production capacity exceeding 10 million casters, with over 110 automated production machines including precision injection molding, automatic punching, riveting, and assembly lines.
TENG® - Our Registered Brand
TENG® is registered in China (since 2006) and internationally under the Madrid System in France, Germany, the United States, Japan, Australia, and Canada (since 2012) - proof of our long-term commitment to brand quality and global presence.
FAQ
Q1: What is the load capacity of this 2 inch swivel caster?
A: This 2 inch swivel caster has a load capacity of 100 kg per caster. For cabinets, equipment, or enclosures with four casters, the total capacity is 400 kg. However, please note that the effective load per caster should be calculated as Total Load ÷ 3 (allowing for uneven weight distribution) rather than Total Load ÷ 4.
Q2: Why is the low 73mm load height important for cabinet and equipment applications?
A: The low 73mm load height provides: Lower center of gravity - significantly reduces the risk of tipping for tall cabinets and equipment; Improved stability - keeps equipment close to the ground during movement; Easier loading - low profile allows equipment to sit closer to the floor; Space efficiency - ideal for applications where low overall height is required. For server cabinets, medical equipment, and tall enclosures, a low load height is critical for safe, stable mobility.
Q3: What is the advantage of the wide 43mm wheel?
A: The 43mm wide wheel provides: Better load distribution - spreads the 100kg load across a wider contact area, reducing pressure on floors; Enhanced stability - wider contact patch improves rolling stability; Smoother rolling - handles floor imperfections better than narrow wheels; Reduced floor damage - less pressure per unit area reduces the risk of marking or indenting floors. The wide wheel design is particularly important for heavy equipment applications.
Q4: What are the advantages of PA (nylon) wheels for equipment applications?
A: PA (nylon) wheels offer: High load capacity - maintains structural integrity under heavy loads; Wear resistance - withstands frequent use across various floor types; Low rolling resistance - smooth rolling for easy movement; Impact resistance - resists shocks and impacts without cracking; Chemical resistance - resists oils, solvents, and many chemicals. These characteristics make nylon the preferred choice for industrial and commercial equipment applications.
Q5: What equipment is this 2 inch swivel caster suitable for?
A: This 2 inch swivel caster is suitable for: Server cabinets - data center racks and network cabinets; Medical equipment - hospital equipment and medical device stands; Industrial enclosures - electrical cabinets and control panels; Commercial machines - vending machines and retail equipment; Laboratory equipment - lab benches and instrument stands; Display equipment - heavy display stands and fixtures.
Q6: What is the mounting specification for this caster?
A: This caster uses top plate mounting with the following specifications: Top plate size - 92.2 × 60.4mm; Bolt hole spacing - 76.2-68.4 × 44.4mm (slotted holes for adjustment flexibility). This mounting pattern is compatible with many standard cabinet and equipment mounting configurations. Please confirm compatibility with your equipment before ordering.
Q7: Is this caster suitable for heavy duty applications?
A: Yes. Despite its compact 2-inch size, this caster is designed for heavy-duty applications with a 100kg load capacity per caster. The wide 43mm nylon wheel and low-profile design provide stable, reliable performance for cabinets, equipment, and industrial enclosures. For applications requiring even higher load capacities, we offer larger heavy-duty caster series - please contact our sales team for recommendations.
Q8: What is the advantage of the 15mm offset?
A: The 15mm offset provides compact maneuverability for cabinet and equipment applications. This small offset allows the caster to turn smoothly in tight spaces while maintaining load stability - ideal for cabinets and equipment that need to navigate around obstacles in confined areas. The low offset also contributes to the caster's low-profile design.
Q9: What certifications does Xingteng hold?
A: Xingteng holds ISO 9001:2015 Quality Management certification, TUV Product Certification for multiple product series, and RoHS 2.0 environmental compliance. We are also a recognized AA-level "Contract-Honoring and Credit-Worthy Enterprise" in Zhejiang Province.
Q10: Does Xingteng offer custom low-profile caster solutions?
A: Yes. With over 30 years of manufacturing experience and in-house engineering capabilities, we offer custom caster solutions including: special wheel materials, custom mounting plates, specific load heights, bearing configurations, and application-specific designs for cabinets, equipment, and industrial enclosures. Contact our sales team to discuss your requirements.
Q11: What is the typical lead time for this 2 inch swivel caster?
A: Standard lead time is typically 20-45 days depending on order quantity. For urgent requirements, please contact our sales team for expedited options. Large-volume orders may require additional lead time - we will confirm exact timing at the time of order placement.
