Products Description
The heavy duty caster with brake is a high-capacity mobility solution engineered for heavy equipment, workbenches, industrial machinery, and demanding workshop applications. With a 350kg load capacity per caster, this heavy duty locking caster provides reliable support with smooth rolling performance, exceptional durability, and secure locking capability - essential for industrial environments where heavy equipment needs to be moved safely and positioned securely.
The impact on your daily operations: When heavy equipment and machinery need to be repositioned for maintenance, reconfiguration, or installation, reliable high-capacity casters are essential for safe and efficient operation. The PU on Cast Iron core wheel delivers exceptional load-bearing capacity with floor-protective rolling - allowing heavy loads to move smoothly with minimal effort, reducing the risk of worker injury and equipment damage. The total lock brake engages with a simple press, locking both the wheel and swivel mechanism to keep equipment securely in place during use.
The PU on Cast Iron core wheel offers the ultimate combination of durability, load capacity, and floor protection. The cast iron core provides exceptional structural strength and heat dissipation for heavy loads, while the PU tread delivers smooth, quiet, non-marking rolling that protects factory and workshop floors. This construction is specifically engineered for the most demanding industrial applications where both load capacity and floor protection are essential. Optional wheel materials (PU, TPR, Nylon, PP, Cast Iron, PU on Iron, Rubber on Cast Iron) and bearing options (Roller Bearing, Double Ball Bearing) are available for applications with specific load, speed, or environmental requirements.
Available with robust top plate mounting (98 × 114mm) for secure attachment to heavy equipment and workbenches. The total lock brake ensures complete stationary security when equipment needs to remain in position. The 150mm diameter with 50mm wide wheel provides excellent rolling efficiency and load distribution for heavy-duty industrial applications.
Technical Specifications
|
Parameter |
Specification |
|
Model No. |
816F1ZDWG601 |
|
Caster Type |
Swivel Caster with Total Lock Brake |
|
Wheel Diameter |
150 mm (6″) - 4″, 5″, 8″ available |
|
Wheel Width |
50 mm |
|
Wheel Material |
PU on Cast Iron Core |
|
Load Capacity |
350 kg per caster |
|
Mounting Type |
Top Plate |
|
Top Plate Size |
98 × 114 mm |
|
Bolt Hole Spacing |
71 × 85 mm |
|
Bolt Hole Diameter |
11 × 20 mm |
|
Offset |
45 mm |
|
Load Height |
195 mm |
|
Bearing Options |
Roller Bearing, Double Ball Bearing |
|
Wheel Options |
PU, TPR, Nylon, PP, Cast Iron, PU on Iron, Rubber on Cast Iron |
Key Features
350kg Load Capacity - reliable support for heavy equipment and machinery
PU on Cast Iron Core Wheel - exceptional load capacity with floor-protective rolling
Total Lock Brake - locks both wheel and swivel for complete stationary security
Robust Top Plate Mounting - 98 × 114mm plate with heavy-duty bolt hole spacing
Multiple Bearing Options - Roller Bearing or Double Ball Bearing available
Multiple Wheel Material Options - PU, TPR, Nylon, PP, Cast Iron, PU on Iron, Rubber on Cast Iron
Why Choose Xingteng TENG® Casters?
30+ Years of Manufacturing Excellence
Xingteng Group has been manufacturing casters since 1997, with manufacturing origins predating our official registration. With over 30 years of continuous innovation and quality improvement, our experience means we understand not just how to make casters, but how to make them right for your specific application - especially when it comes to heavy duty casters for demanding industrial environments.
ISO 9001:2015 Certified Quality Management
Our quality management system is certified to ISO 9001:2015, ensuring consistent product quality, traceable production processes, and continuous improvement - exactly what industrial buyers expect from a reliable supplier.
TUV Product Certification
Multiple product series have passed TUV testing and certification - proof that our products meet internationally recognized safety and performance standards.
RoHS 2.0 Compliant
All products meet RoHS 2.0 European environmental protection standards, ensuring your supply chain remains compliant with international environmental regulations.
In-House Testing Laboratory
Our dedicated testing facility is equipped with dynamic loading testers, impact testers, static pressure testers, hardness testers, brake life testers, salt spray testers, optical profile projector, and caster creep tester - every heavy duty caster is verified before it leaves our factory.
30,000+ sqm Manufacturing Facility
Annual production capacity exceeding 10 million casters, with over 110 automated production machines including precision injection molding, automatic punching, riveting, and assembly lines.
TENG® - Our Registered Brand
TENG® is registered in China (since 2006) and internationally under the Madrid System in France, Germany, the United States, Japan, Australia, and Canada (since 2012) - proof of our long-term commitment to brand quality and global presence.
FAQ
Q1: What is the load capacity of this heavy duty caster with brake?
A: This heavy duty caster has a load capacity of 350 kg per caster. For heavy equipment or workbenches with four casters, the total capacity is 1,400 kg. However, please note that the effective load per caster should be calculated as Total Load ÷ 3 (allowing for uneven weight distribution) rather than Total Load ÷ 4.
Q2: What is the advantage of the PU on Cast Iron core wheel construction?
A: The PU on Cast Iron core construction offers the best combination for heavy-duty applications: Cast iron core - provides exceptional structural strength, heat dissipation, and durability under heavy loads; PU tread - delivers smooth, quiet, non-marking rolling that protects factory and workshop floors. This construction is specifically engineered for demanding industrial environments where both high load capacity and floor protection are essential.
Q3: What wheel material options are available for this heavy duty caster?
A: This heavy duty caster series is available with seven wheel material options: PU on Cast Iron - standard option offering exceptional load capacity with floor protection; PU - excellent wear resistance and floor protection; TPR - quiet, non-marking operation; Nylon - superior impact resistance; PP - lightweight and chemical-resistant; Cast Iron - extreme durability for the heaviest loads; Rubber on Cast Iron - superior shock absorption with iron core strength. Choose based on your load, floor type, and application requirements.
Q4: What is the difference between Roller Bearing and Double Ball Bearing?
A: Roller Bearings use cylindrical rollers to handle heavier radial loads, making them ideal for high-load, slow-speed applications where durability is the priority - recommended for heavy equipment and machinery. Double Ball Bearings use two rows of balls to handle both radial and moderate thrust loads, providing smoother rolling with less friction - ideal for applications requiring frequent movement and maneuverability. Choose based on your load, speed, and maneuverability requirements.
Q5: What is a total lock brake and why is it important for heavy equipment?
A: A total lock brake locks both the wheel (preventing rolling) and the swivel mechanism (preventing rotation) simultaneously. This is critical for heavy equipment because: Safety - equipment remains completely fixed during loading and unloading; Stability - prevents unexpected movement on sloping surfaces; Worker protection - reduces the risk of injury during maintenance and operations. This brake type is essential for heavy-duty applications where equipment must remain completely secure when stationary.
Q6: What equipment is this heavy duty caster suitable for?
A: This heavy duty caster is suitable for: Heavy equipment - industrial machinery and large equipment; Workbenches - heavy-duty workshop workbenches; Industrial carts - heavy-duty platform trucks and material handling carts; Moving heavy equipment - equipment relocation and positioning; Leveling applications - heavy equipment requiring stable positioning; Factory machinery - production line equipment and machine stands.
Q7: What is the mounting specification for this heavy duty caster?
A: This caster uses top plate mounting with the following specifications: Top plate size - 98 × 114mm; Bolt hole spacing - 71 × 85mm; Bolt hole diameter - 11 × 20mm (slotted holes for adjustment flexibility). This heavy-duty mounting pattern ensures secure attachment for large equipment and workbenches. Please confirm compatibility with your equipment before ordering.
Q8: What is the difference between this caster and standard duty casters?
A: This heavy duty caster is specifically designed for heavy industrial applications: 350kg load capacity vs 50-100kg for standard duty; PU on Cast Iron core vs standard PU or nylon; 150 × 50mm wheel vs smaller wheels; 195mm load height for heavy equipment clearance; Robust 98 × 114mm mounting plate. Standard duty casters are not suitable for heavy equipment or machinery.
Q9: How does the 195mm load height benefit heavy equipment applications?
A: The 195mm load height provides: Adequate clearance - sufficient space for equipment base and floor clearance; Stability - appropriate center of gravity for heavy equipment stability; Ergonomic handling - comfortable height for maneuvering heavy loads; Floor clearance - enough clearance for floor irregularities without bottoming out.
Q10: Is this caster suitable for use on uneven factory floors?
A: The PU on Cast Iron core wheel provides good performance on moderately uneven floors. For significantly uneven surfaces or applications requiring maximum shock absorption, we recommend Rubber on Cast Iron wheels which offer superior vibration dampening. Please contact our sales team for recommendations based on your specific floor conditions.
Q11: What certifications does Xingteng hold?
A: Xingteng holds ISO 9001:2015 Quality Management certification, TUV Product Certification for multiple product series, and RoHS 2.0 environmental compliance. We are also a recognized AA-level "Contract-Honoring and Credit-Worthy Enterprise" in Zhejiang Province.
Q12: What is the typical lead time for this heavy duty caster?
A: Standard lead time is typically 20-45 days depending on order quantity, wheel material selection, and bearing configuration. For urgent requirements, please contact our sales team for expedited options. Large-volume orders may require additional lead time - we will confirm exact timing at the time of order placement.
